建筑硅酮密封胶相关规范与标准
类别:辅材与设备  日期:2021-10-29  来源:兴发凌志   点击率:84900  打印 关闭



    从密封胶应用的角度来看,影响密封性能与寿命的三大因素有设计、选材以及施工,其中正确选材又是中间承前启后的关键环节。选材的依据有很多,其中最基本的是依据应用场景选择符合相应标准的密封胶产品。为此本文梳理了现行的中国、美国以及欧盟关于建筑(硅酮)密封胶相关的技术规范与产品标准。




    由于篇幅原因,只列出了主规范与标准,相关支持性标准如术语,检测方法等未列出,因为它们可以通过主标准/规范的参考引用很容易得到。



1建筑幕墙



1.1 中国

1.1.1 幕墙工程技术

1JGJ 102-2003 玻璃幕墙工程技术规范

2JGJ 133-2001 金属与石材幕墙工程技术规范

3JGJ 336-2016 人造板材幕墙工程技术规范



1.1.2 幕墙结构胶

4JG/T475-2015 建筑幕墙用硅酮结构密封胶

5GB 16776-2005 建筑用硅酮结构密封胶

6GB/T 37126-2018 结构装配用建筑密封胶试验方法标准



1.1.3 幕墙密封胶

7GB/T 22083-2008 建筑胶粘剂分级和要求

8GB/T 14683-2017 硅酮和改性硅酮建筑密封胶

9GB/T 13477-2017 建筑密封材料试验方法 系列标准

10GB/T 24267-2009 建筑用阻燃密封胶

11GB 23864-2009 防火封堵材料

12JC/T 881-2017 混凝土接缝用建筑密封胶

13JC/T 882-2001 幕墙玻璃接缝用密封胶

14GB/T 23261-2009 石材用建筑密封胶

15JC/T 884-2016 金属板用建筑密封胶_建筑材料标准

16JC/T 885—2016 建筑用防霉密封胶

17JC/T 485-2007 建筑窗用弹性密封胶



1.2 美国

1.2.1 结构装配

1) ASTM C1401-14 Guide for StructuralSealant Glazing

2) ASTM C1392-2000 R2005 Guide forEvaluating Failure of Structural Sealant Glazing

3) ASTM C1392-2000 R2012 Guide for In-SituStructural Silicone Glazing Evaluation

4) ASTM 1487-19 Guide for RemedyingStructural Silicone Glazing

5) ASTM C1184-14 Specification forStructural Silicone Sealants



1.2.2 接缝密封

6) ASTM C1193-2013 Guide for Use of JointSealants

7) ASTM C1472-2010 Guide for CalculatingMovement and other effects When establish Sealant Joint Width

8) ASTM C1481-12 Guide for Use of JointSealants with Exterior Insulation and Finish Systems EIFS

9) ASTM C920-18 Specification forElastomeric Joint Sealants



1.3 欧盟

1.3.1 结构装配

1) EN13022:2014 Glass in building-Structural Sealant Glazing

Part 1: Glass products for SSGS forsupported and unsupported monolithic and multiple Glazing

Part2: Assemble Rules

2) EN15434:2006 Glass in Building -Product standard for structural and orultra-violet resistant

  Sealant(for use with SSG and/or IGU with exposed seals)

3) ETAG 0021999 Guideline for European Technical Approval for SSGS, amended Oct 2001



1.3.2 接缝密封

4) EN12488:2016 Glass in Building- Glazing recommendations - Assembly principles forvertical and sloping glazing(非结构装配)

5) EN15651-2017: Sealants for non-structural use in joints in buildings andpedestrian walkways

  Part 1: Sealants for facade elements

  Part 2: Sealants for Glazing

  Part 3: Sealants for sanitary joints

  Part 4: Sealants for pedestrian walkways

  Part 5: Assessment and verification of constancy of performance, markingand labelling.





2 中空玻璃类







2.1 中国

1GB/T 11944-2012 中空玻璃

2GB/T 29755-2013 中空玻璃用弹性密封胶

3GB 24266-2009 中空玻璃用硅酮结构密封胶

4JC/T 486-2001 中空玻璃用弹性密封胶(2014年已废止)



2.2 美国

1) ASTME 2190-2019 Specification for Insulating Glass Unit Performance and Evaluation

2) ASTMC1249-18 Secondary Seal for Sealed Insulating Glass Units for StructuralSealant Glazing Applications

3) ASTMC1369-19 Specification for Secondary Edge Sealants for Structurally GlazedInsulating Glass Units



2.3 欧盟

1) EN 1279:2018 Glass in Building - Insulating glass units

  Part 1: Generalities, system description, rules for substitution,tolerances and visual quality

  Part 2: Long term test method and requirements for moisture penetration

  Part 3: Long term test method and requirements for gas leakage rate andfor gas

concentration tolerances;

  Part 4: Methods of test for the physical attributes of edge sealcomponents and inserts

  Part 5: Factory Production control periodic tests.

2) EN15434:2006 Glass in Building -Product standard for structural and orultra-violet resistant

Sealant (for use with SSG and / or IGU with exposed seals)


C:\Users\Administrator\Documents\WeChat Files\wxid_aydad6spfgtn22\FileStorage\Temp\d3dbc6f854b75077ac254b8fe9254b7d.png





来源:兴发凌志 钟天平
